Antistatic Wedge V belt(belt teeth)

  • Model:Antistatic Wedge V belt(belt teeth)
  • Feature:

    Environmental protection: the material of the product is thermoplastic elastomer, with the characteristics of wear-resistance, acid and alkali resistance, oil resistance, and corrosion resistance. The finished product does not need die sinking or sulfuration. It has advantages such as environmental friendly and no foreign flavor. Full-automatic production: use teeth structure with good flexibility, fast heat dissipation, and stable operation. The product is produced by full-automatic equipment and the length can be as accurate as 1mm. Besides, it can produce any-length high-strength polyester rope. High-strength polyester rope: the product rope uses high-quality rigid rope with the following advantages: tensile resistance is strong; belt is not easy to draw out; the diameter of the whole rope is uniform and shape is nice. Wedge Belt characteristics

  • Update:2013-5-2
  • Unit:Shanghai Vector Power Co., Ltd
TYPE Sectional dimension
(W*H)
Standard length
(mm)

Pitch diameter of

 smallest pulley

Section schematic

diagram

3V-AS 9*8 LA(outside length) 63
5V-AS 15*3 140
8V-AS 25*23 335
SPZ-AS 9.7*8 LP(pitch length) 63
SPA-AS 12.7*10 90
 SPB-AS  16.3*13  140
 SPC-AS  22*18  224
